BANGLADESH Incinerator (Model TS20 Gas with wet scrubber)
a) lncineration capacity: 75 kg/hr.– up to 100kgs/hour b) Number of combustion chamber: Two (02)—yes c) Operating temperature in primary chamber: 850±50 °C— 800°C-1000°C d) Operating temperature in secondary chamber: 1200±50 °C— 1000°C-1300°C e) Burner type: Pressure jet diesel fired—yes f) Power system: Three phase, 50 Hz, 380 – 440 VAC—yes g) MOC: Vendor to specify h) Refractory material: Vendor to specify i) Dimension: Vendor to specify j) Stack height 30 meters—yes k) Auto feeding system—yes l) Ash collection system—yes m) Temperature monitoring system—yes n) Burner safety control system—yes
Tel: +86-25-8461 0201 Mobile: +86-13813931455(whatsapp/wechat) Website: www.hiclover.com Email: sales@hiclover.com Email: hicloversales@gmail.com Incinerator Items/Model HICLOVER TS20(PLC) Burn Rate (Average) 20-30 kg/hour Feed Capacity(Average) 40kg/feeding Control Mode PLC Automatic Primary Combustion Chamber 210L Internal Dimensions 65x65x50cm Secondary Chamber 110L Feed Mode Manual Voltage 380V 3P Power 5.0Kw Burner Type Italy Brand N.Gas Consumption (m3n/hour) 8-15.7 Temperature Monitor Yes Temperature Thermometer Corundum Probe Tube, 1400℃Rate. Temperature Protection Yes Automatic Cooling Yes Automatic False Alarm Yes Automatic Protection Operator(APO) Yes System Testing Model Yes Time Setting Yes Progress Display Bar LCD Display Feeding Door 45x40cm Chimney 3Meter Chimney Type Stainless Steel 304 1st. Chamber Temperature 800℃–1000℃ 2nd. Chamber Temperature 1000℃-1300℃ Residency Time 2.0 Sec. Gross Weight 2700kg External Dimensions(Incinerator Mainbody) 160x110x130cm 1st. Chamber Composition Hot Face Thickness: ≥115 mm 55% of Al203 1750°C Grade 2nd. Chamber Composition Hot Face Thickness: ≥115 mm 75% of Al203 1790°C Grade Chamber Cold Face Material High Rate Refractory Ceramic Fiber Other Parts Hot Face Refractory Heavy Duty with steel fiber Burner operation Automatic On/Off Wet Scrubber Including Paint for outside face 250°C Grade Sealing Material Refractory Ceramic Fiber
